Railroad Loader T10000FS
Send an Inquiry
Contact us for more information about this model.

Railroad Loader T10000FS

T10000FS Specifications

ENGINE:
  • 4 CYLINDER DEUTZ DIESEL, D.I. TURBO CHARGED
  • 156 HORSEPOWER AT 2300 RPM
  • WATER COOLED
  • 63 GALLON FUEL TANK CAPACITY
  • ELECTRICAL SYSTEM VOLTAGE OF 24 VOLTS
HYDRAULICS:
  • N.2 AXIAL PISTON PUMPS VARIABLE
  • TOTAL MAX. FLOW 46 + 46 GAL/MIN
  • MAX. PRESSURE: 5000 PSI
  • 55 GALLON HYDRAULIC OIL TANK CAPACITY
 CAB:
  • ALL-ROUND VISIBILITY
  • SOUND INSULATED
  • ANATOMICALLY DESIGNED DOUBLE SEAT
  • AIR CONDITIONING, VENTILATION AND HEATING SYSTEM
TRANSMISSION:
  • ALL-WHEEL, HYDROSTATIC TRANSMISSION
  • HYDRAULIC AXIAL PISTON MOTOR VARIABLE DISPLACEMENT
  • 3-SPEED GEARBOX TO DRIVE THE AXLES WITH PLANETARY REDUCTION ON HUB WHEELS
  • ROAD SPEED: 13 MPH
  • RAIL SPEED: 13 MPH
 BOOM:
  • EXTENSION: 25 FT 11 IN. REACH
 TIRES:
  • N.8, 9.00 R20 XZM
HI-RAIL SYSTEM:
  • RAIL TRANSMISSION BY FRICTION FROM TIRES TO RAIL WHEELS
  • FRONT FLOATING AXLE AND HYDRAULIC SWING LOCKING CYLINDERS
 TURRET:
  • TURRET SLEW: 360° CONTINUOUS
  • COUNTERWEIGHT: EXTENDABLE
  • TAIL SWING: 5FT 9 IN TO 8FT 10 IN
  • SWING SPEED MAX.: 8 RPM
 TOTAL WEIGHT:
  •  70,600 LBS.
